China hot sale IP67 lithium battery solar led light charge controllers with microwave motion sensor
$13.8
/piece
price excl.VAT
Negotiable
- Minimal order
- 100 pieces
Message Phone call
Product Specifications
--
Product Description
Overview
Quick Details
Place of Origin:Jiangsu, China
Brand Name:PTDT
Model Number:CLL12/2408LI-WB
Type:PWM
Application:Charger Controller, Lighting Controller
Work Time (h):24hours
Max PV Power:130WP(12V)/260WP(24V)
Max PV Voltage:DC55V
Protection level:IP 67
Charging mode:PWM
LED indicators:Yes
Battery type:Li-ion / LiFePO4
Max load power:40W
Certification:CE, ISO, CQC
OEM service:accepted
Dimming value:0-100% output power
Sensor:Microwave Motion Sensor
With built-in led driver:Yes
Packaging & Delivery
Selling Units:Single itemSingle package size: 14X10X4 cm Single gross weight: 0.200 kgPackage Type:20pcs/carton36pcs/carton41cm*26cm*29cm Picture Example:
Lead Time :
| Quantity(Pieces) | 1 - 100 | 101 - 500 | >500 |
| Est. Time(days) | 3 | 7 | To be negotiated |
Online Customization
Product Description
CLL12/2408LI-40W is solar light controller for lithium battery. This solar light controller is integrated with LED driver, so the led light can't have LED driver. And this also can save the cost of LED driver. Adopting advanced circuit design and intelligent driving program, this controller has high charging/discharging efficiency and stability. The output current can be adjusted for 4 time frames. With fully sealed waterproof design and wide output voltage, the product applies to most LED solar street lights.
Specifications
| Model | CLL12/2408LI-WB | |||
| Input Voltage | DC 9V-32V auto adaptive | |||
| Output voltage | Battery's peak volt plus 1V~70V | |||
| Static power | ≤10mA | |||
| Max.charging current | 8A | |||
| Max.output power | 40W | |||
| Max.charge conversion efficiency | 96% | |||
| Output current error | ±3% | |||
| Output current | 50mA-2600mA (programmable) | |||
| Max.solar panel | 130WP(12V system)/260WP(24V system) | |||
| Max.solar panel voltage | DC55V | |||
| Working temperature | -35℃~60℃ | |||
| Charging mode | PWM | |||
| Working mode | Light controlling,time controlling,output current adjustable in 3 time intervals | |||
| Delay time | 0~200 seconds | |||
| Over-charging protection voltage | DC 9V-32V adjustable | |||
| Under voltage protection | DC 9V-32V adjustable | |||
| Exit under voltage protection | DC 9V-32V adjustable | |||
| Weight | 150g | |||
| Dimensions | 67mm×77mm×18mm | |||
| Application | 40W 15-70V LED(12V), 40W 29-70V LED(24V) | |||
Product Features
1) Adopt the integrating technology of control and LED driver, and save the cost of the LED driver power supply for users.
2) Adopting advanced and intelligent circuit design, this controller still can work even after the lithium battery enters under-voltage protection state.
3) Designed for lithium battery, input voltage is 9V-32V and automatically recognized.
4) Max output voltage reaches 70V. Most values, such as over-charging protection, over-discharging protection and exit over-charging protection are adjustable, which matches lithium battery's characteristics highly.
5) With the function of 3 time frames power regulation, Users can dim LED lamps' output power.
6) The controller adopts fully sealed waterproof design. The IP grade reaches IP67. The controller can be used in the water.
7) This controller can withstand from -35℃ to 60℃ high and low temperature, so it can adapt to extreme temperature.
8) This controller can drop load's power automatically according to the left capacity of battery, and this feature helps the solar street light work for more days.
9) Automatic time controlling at dusk and dawn.
Related Products
CLM MPPT solar lighting controller with step-up LED Driver
CLLM MPPT solar lighting controller with step-up LED Driver Lithium
DC-DC LED Driver for LED lights
CLL PWM solar lighting controller with step-up LED Driver Lithium
CL PWM solar lighting controller with step-up LED Driver
TL PWM solar lighting controller with step-down LED Driver
DT PWM solar lighting controller without LED Driver
AT PWM hybrid solar lighting controller
CLL-WB solar lighting controller with microwave motion sensor
Our Company
Nanjing Putian Datang Information Electronics Co., Ltd. is a subsidiary company of Hongkong Stock Exchange (HKEX) listed state-owned Nanjing Putian Telecommunications Co., Ltd., established in 1958 and a member of Potevio Group wholly owned by the China Central Government.
We are the leader in solar system control technology, with major products including PWM & MPPT solar charge controller for diversified solar systems, IoT solar street light remote control systems, LED drivers, inverters, inverter charge controller combos, etc. Most of our products are CE certified. We have been committed to developing more intelligent digital solar control products and solutions for more energy-efficient renewable energy systems, as a part of global efforts to create a greener earth for our future generations.
We are located in Nanjing, provincial capital of Jiangsu, a UNESCO historic and cultural city, as well as a modern metropolis and national pivotal transportation hub near Shanghai. We have our own industrial park covering more than 50,000m2 with ISO9001 certification. Our manufacturing facilities include: over 10,000 square meters standardized electronic plants, 3 advanced imported automatic SMT production lines, several wave soldering production lines, assembly, test and aging workshops and standard type test lab to implement high-low temperature test, salt spray test, vibration test and aging test. Complete facilities, as well as highly skilled and dedicated staff, lay the foundation for our premium quality.
Putian solar lighting controllers used in African projects
Certifications
Packing & Delivery
Packing
Samples and bulk orders will be packed well in our factory, there is no any damage during shipping.
Delivery
Diffrent shipping ways for buyers to choose.
FAQ
Q1: Can I get one for sample ?
A1:Yes, we accept sample order or trial order for testing firstly.
Q2: What's the price and MOQ ?
A2: Please just send me inquiry, your inquiry will be replied within 24 hours, we will let you know the latest price and MOQ.
Q3: What's you delivery time ?
A3: It depends on your quantity, but usually, 5-10 days for sample order, 10-20 days for batch order.
Q4: How about your payment and shipment ?
A4: Payment: We accept T/T, Western Union,Paypal etc. terms of payment.
Shipment: For sample order, we use DHL, TNT, FEDEX etc; For batch order, by sea or by air( through our forward)
Q5:How about your warranty ?
A5: We provide 2 years or 3 years warranty for different products and whole life technical support.
Q6.Do you have you own factory ?
A6: Yes,we are professional manufacturer mainly in solar controller for about 13 years.Our factory is located in Nanjing,Jiangsu,China.
